Duplex House Plans For 40x35 ft Site RQ0007

This is a north-facing 40 x 35 ft (12.2 x 10.67 m ) 4BHK duplex house plan, provided with special features like living hall, balcony, study room, and many other special features. This is a three-floor building. Ground floor consists of spacious parking area, living hall, two bedrooms with attached washroom, kitchen, and the dining hall. The first floor consists of two bedrooms with attached washroom, family hall, balcony, and the study room. The terrace floor consists of open terrace along with the headroom.

The ground floor Living area measures about 10 feet 7 inches and 12 feet 1 inches. spacious parking area measuring about 11 feet 11 inches and 17 feet located in the northwest direction. The main door of this house is in north direction. The kitchen in the southeast direction measures about 13 feet 1 inches and 7 feet 3 inches. The setback area at backside is 2 feet, at right and left side it is 2 feet.The first bedroom in the southwest direction measures about 12 feet 4 inches and 13 feet 7 inches, with the common bathroom measuring about 7 feet 8 inches and 5 feet 4 inches. The bedroom in the northeast direction measures about 12 feet 11 inches and 8 feet 11 inches.

The first floor The study room located in the southeast direction measures about 12 feet, 11 inches, and 7 feet. The first bedroom in the southwest direction measures about 12 feet 4 inches and 13 feet 7 inches, with the common bathroom measuring about 7 feet 8 inches and 5 feet 4 inches. The bedroom in the northeast direction measures about 12 feet 11 inches and 8 feet 11 inches. The family hall located in the first floor measures about 10 feet, 7 inches, and 12 feet, 9 inches. The balcony measures about 9 feet, 7 inches, and 13 feet, 2 inches in the northwest direction directly connected to the family hall.

The terrace floor consists of open terrace measuring about 33 feet 8 inches and 8 feet 10 inches the hedroom measures about 7 feet 3 inches and 9 feet 10 inches.
