15 x 40 ft House Plan With Car Parking Of The Residential Building

North facing 3BHK Duplex house plan is constructed on the 15 x 40 ft (4.57 x 12.19 m) plot with Ground + 2 Floor structure. The layout of this house is designed efficiently and allows proper light and sunlight which air flow inside, it improves overall living experience.

Ground Floor

Ground floor which covers parking area 14.00 x 13.83 ft (4.27 x 4.21 m) offers enough space for bike or cars. The main door placed at the northeast direction facing north side which is direct entry of the home that connect to the living hall.A pooja room size of 2.50 x 3.00 ft (0.76 x 0.91 m) is placed at the northeast direction serve for ideal worship. An open kitchen size of 8.25 x 6.58 ft (2.51 x 2.00 m) is located in the southeast corner which is compact efficient that make usable for both cook and serve.

First Floor

Move to first floor, three bedrooms are beautifully designed in this floor.Kids bedroom size of 6.58 x 8.25 ft (2.00 x 2.51 m) in the northeast direction which is more comfort and secured. The common bathroom size of 6.42 x 3.50 ft (1.96 x 1.07 m) in the west direction which is easily accessible from all the room.For laundry space occupies 5.25 x 3.67 ft (1.60 x 1.12 m) beside bathroom is provided.The bedroom size of 12.17 x 7.00 ft (3.71 x 2.13 m) in the west direction which can be used for both residents or guests.Master bedroom size of 10.50 x 12.17 ft (3.20 x 3.71 m) in the northwest direction with attached bathroom size of 6.42 x 3.50 ft (1.96 x 1.07 m) which is luxurious retreat and privacy. Attached balcony size of 12.17 x 2.58 ft (3.71 x 0.79 m) in the north which is an ideal location for gardening and enjoying outdoor views.

Second Floor

A spacious open terrace size of 37.33 x 12.17 ft (11.38 x 3.71 m) suited for relaxation, fun or gardening and do any family functions. Windows are placed for ventilation that enhance the airflow and natural illumination for this space.
